SCT54400.pdf? Qualified for Automotive Applications
? AEC-Q100 Qualified With the Following Results:
Device Temperature Grade 1: –40°C to 125°C
Ambient Operating Temperature Range
Device HBM ESD Classification Level H2
Device CDM ESD Classification Level C4B
? Quad-Channel 1000-mΩ Smart High-Side Switch
With Full Diagnostics
Version A: Open-Drain Status Output
Version B: Current-Sense Analog Output
? Wide Operating Voltage 3.4 to 40 V
? Ultralow Standby Current, <500 nA
? High-Accuracy Current Sense:
±15% Under >5-mA Load
? Adjustable Current Limit With External Resistor
±20% Under >100-mA Load
? Protection:
Short-to-GND Protection by Current Limit
(Internal or External)
Thermal Shutdown With Latch-Off Option and
Thermal Swing
Inductive Load Negative Voltage Clamp With
Optimized Slew Rate
Loss of GND and Loss of Battery Protection
? Diagnostic:
Overcurrent and Short to Ground Detection
Open-Load and Short-to-Battery Detection
Global Fault for Fast Interrupt
? 20-Pin Thermally-Enhanced PWP Package
