? ESD Protect for 4 high-speed I/O channels

  with Bi-directional

? Provide ESD protection for each line to

  IEC 61000-4-2 (ESD) ±15kV (air), ±15kV (contact)

  IEC 61000-4-4 (EFT) 40A (5/50ns)

  IEC 61000-4-5 (Lightning) 5A (8/20μs)

? For operating voltage of 5V and below

? Ultra low capacitance : 0.40pF typical

? Fast turn-on and Low clamping voltage

? Array of ESD rated diodes with internal equivalent

  TVS (Transient Voltage Suppression) diode

? Simplified layout for high-speed differential

  signaling channels

? Solid-state silicon-avalanche and active circuit

  triggering technology Green part
