SGM2036.pdf? Low Dropout Voltage
? Thermal Overload Protection
? Built-In Fold Back Protection Circuit
? 20μA Low Supply Current
? 10nA Logic-Controlled Shutdown
? 1.6V to 5.5V Input Voltage Range
? Fixed Outputs of 0.8V, 0.9V, 1.0V, 1.05V, 1.1V,
1.2V, 1.3V, 1.35V, 1.5V, 1.8V, 1.85V, 2.1V, 2.2V,
2.3V, 2.5V, 2.6V, 2.7V, 2.8V, 2.85V, 2.9V, 3.0V, 3.1V,
3.3V, 3.6V, 4.2V, 4.4V and 5.0V
? Adjustable Output from 0.8V to 5.0V
? Short Auto-Discharge Function
? 300mA Output Current
? High Output Voltage Accuracy
? Short Start-Up Time
? -40℃ to +85℃ Operating Temperature Range
? Available in Green UTDFN-1×1-4L, SOT-23-5 and
SC70-5 Packages
? 200mA Low Dropout Regulator with EN
? Low IQ: 40mA
? Multiple Output Voltage Versions Available:
Fixed Outputs of 1.2V to 4.5V Using
Innovative Factory EEPROM Programming
Adjustable Outputs from 1.20V to 6.5V
? High PSRR: 66dB at 1kHz
? Ultra-low Noise: 29.5mVRMS
? Fast Start-Up Time: 45ms
? Stable with a Low-ESR, 2.0mF
Typical Output Capacitance
? Excellent Load/Line Transient Response
? 2% Overall Accuracy (Load/Line/Temp)
? Very Low Dropout: 100mV
? ThinSOT-23, WCSP, and 2mm × 2mm SON-6 Packages
