SGM2058.pdf? Input Voltage Range: 2.3V to 5.5V
? Dual Outputs:VOUT1: -VIN
(Unregulated Negative Charge Pump Output)
VOUT2: -VCTL between 0V and -VIN
(Regulated Output)
? Output Current Limit: 265mA (TYP)
? Stable with Small Case Size Ceramic Capacitors
? Thermal Shutdown Protection
? No Inrush Current during Start-Up
? -40℃ to +125℃ Operating Temperature Range
? Available in a Green TQFN-1.8×1.4-10L Package
? Wiper Position Stored in Nonvolatile Memory and Recalled Upon Power-Up
? 16-Pin, 5mm x 5mm x 0.8mm TQFN Package
? 35ppm/°C End-to-End Resistance Temperature Coefficient
? 5ppm/°C Ratiometric Temperature Coefficient
? 10k? and 50k? End-to-End Resistor Values
? 3-Wire SPI-Compatible Serial Interface
? Reliability (TA = +85°C)
50,000 Wiper Store Cycles
50 Years Wiper Data Retention
? 1.5μA (max) Standby Current
? Single +2.7V to +5.25V Supply Operation
? Dual ±2.5V Supply Operation
