SGM40658.pdf? Protect High-Power Portable Devices
Wide Operating Input Voltage Protection from 2.5V to 28V
Integrated 20mΩ (TYP) N-Channel MOSFET Switch
? Flexible Over-Voltage Protection Design
Adjustable Over-Voltage Protection Trip Level
Wide Adjustable OVLO Threshold Range from 4V to 20V
Internal Preset OVLO Thresholds:
5.95V (SGM40658)
? Additional Protection Features Increase System Reliability
Surge Immunity up to +120V
Soft-Start to Minimize In-Rush Current
Internal 15ms Startup Debounce
Thermal Shutdown Protection
? Enable Function
? -40℃ to +85℃ Operating Temperature Range
? Available in Green WLCSP-1.31×1.84-12B Package
? 4.8A Continuous Current Capability
? Typical RON: 35mΩ N-Channel MOSFET
? VIN Operating Range: 2.1V to 28V
? Overvoltage Lockout :
5.95V(ET9539L/ET9539AL/ET9639L)
? Overvoltage - Protection Response Time:100ns(ET9539 TYP.)
? Overvoltage - Protection Response Time:80ns(ET9539A ET9639 TYP.)
? Startup Debounce Time:21ms(TYP.)
? Internal Thermal-Shutdown Protection
Surge immunity to ±100V(ET9539 series)
Surge immunity to ±160V(ET9539A series)
Surge immunity to ±200V(ET9639 series)
? ESD Protected: Human Body Model : ±2KV
? CSP12 Package (ball pitch=0.4mm)
