SGM61163.pdf? Low Integrated RDSON Switches: 27mΩ/18mΩ
? Split Rails for Supply (VIN) and Power (PVIN)
1.8V to 18V Range for PVIN
4.5V to 18V Range for VIN
? 200kHz to 2MHz Switching Frequency
? External Clock Synchronization
? Voltage Tracking Capability
? 0.6V Internal Reference Voltage
? ±1% Reference Voltage Accuracy
? 3.4μA (TYP) Shutdown Current
? Hiccup Mode Current Limit
? Monotonic Startup with Pre-biased Outputs
? Adjustable Soft-Start Time
? Power Sequencing Capability
? Power Good Output Monitor for Under-Voltage and
Over-Voltage Protections
? Adjustable Input Under-Voltage Lockout (UVLO)
? Integrated 26mΩ / 19mΩ MOSFETs
? Split Power Rail: 1.6V to 17V on PVIN
? 200kHz to 1.6MHz Switching Frequency
? Synchronizes to External Clock
? 0.6V ±1% Voltage Reference Over Temperature
? Low 2uA Shutdown Quiescent Current
? Monotonic Start-Up into Pre-biased Outputs
? –40°C to 150°C Operating Junction Temperature Range
? Adjustable Slow Start/Power Sequencing
? Power Good Output Monitor for Undervoltage
and Overvoltage
? Adjustable Input Undervoltage Lockout
? Supported by SwitcherPro? Software Tool
