7SZ245XTS20G/TR.pdf? Wide Operating Voltage Range: 1.8V to 5.0V
? High-Current 3-State Outputs Drive Bus Lines
Directly or Up to 15 LSTTL Loads
? Low Power Consumption, ICC: 0.1μA (TYP)
? Typical tPD = 12ns
? ±20mA Output Drive at 5V
? Low Input Current: ±0.1nA (TYP)
? Available in Green TSSOP-20, TQFN-5.5×3.5-24L
and TQFN-3×3-20L Packages
? 5V TOLERANT INPUTS AND OUTPUTS
? HIGH SPEED :
tPD = 7.0 ns (MAX.) at VCC = 3V
? POWER DOWN PROTECTION ON INPUTS
AND OUTPUTS
? SYMMETRICAL OUTPUT IMPEDANCE:
|IOH|=IOL = 24mA (MIN) at VCC = 3V
? PCI BUS LEVELS GUARANTEED AT 24 mA
? BALANCED PROPAGATION DELAYS:
tPLH ? tPHL
? OPERATING VOLTAGE RANGE:
VCC(OPR) = 2.0V to 3.6V (1.5V Data Retention)
? PIN AND FUNCTION COMPATIBLE WITH 74 SERIES 245
? LATCH-UP PERFORMANCE EXCEEDS
500mA (JESD 17)
? ESD PERFORMANCE:
HBM > 2000V (MIL STD 883 method 3015); MM > 200V
