? Wide common-mode voltage:

  Operational voltage: ?4 V to +110 V

  Survival voltage: ?20 V to +120 V

? Excellent CMRR:

  120-dB DC CMRR

  65-dB AC CMRR at 50 kHz

? Accuracy:

  Gain:

  Gain error: ±0.5% (maximum)

  Gain drift: ±20 ppm/°C (maximum)

  Offset:
– Offset voltage: ±55 μV (typical)

  Offset drift: ±0.1 μV/°C (typical)

? Available gains:

  INA281A1, INA281B1 : 20 V/V

  INA281A2, INA281B2 : 50 V/V

  INA281A3, INA281B3 : 100 V/V

  INA281A4, INA281B4 : 200 V/V

  INA281A5, INA281B5 : 500 V/V

? High bandwidth: 1.3 MHz

? Slew rate: 2.5V/μs

? Quiescent current: 1.5 mA
