SGM8558-4.pdf? 230mA Output Drive Capability
? Low Input Offset Voltage: 15μV (MAX)
? Low Noise: 8nV/ Hz at 1kHz
? 230mA Current Limitation
? Over-Temperature Protection
? Supply Voltage Range: 2.8V to 5.5V
? Supply Current:
0.86mA/Amplifier (TYP)
0.2μA (TYP) Shutdown Current for SGM8558-3
? Gain-Bandwidth Product: 15MHz
? High Slew Rate: 8V/μs
? Voltage Gain (RL = 2kΩ): 139dB
? Power Supply Rejection Ratio: 130dB
? No Phase Reversal for Overdriven Inputs
? Unity-Gain Stable for Capacitive Loads to 780pF
? -40℃ to +125℃ Operating Temperature Range
? Small Packaging:
SGM8558-1 Available in Green SOIC-8 and
SOT-23-5 Packages
SGM8558-2 Available in Green TDFN-3×3-8L
and SOIC-8 Packages
SGM8558-3 Available in a Green SOT-23-6 Package
SGM8558-4 Available in a Green SOIC-14 Package
? Unmatched Price Performance
? Low Offset Voltage: 2 μV
? Zero Drift: 0.02 μV/°C
? Low Noise: 1.1 μVPP, 0.1 Hz to 10 Hz
? Quiescent Current: 17 μA
? Supply Voltage: 1.8 V to 5.5 V
? Rail-to-Rail Input/Output
? Internal EMI Filtering
? microSize Packages: SOT23, SC70
